SYM86368VGGA艾迅工控主板
日期:2017-11-20 21:35:22

LGA 1150 Intel Core i3/i5/i7 ATX母板,带2VGA/HDMI/DVI,双GbE网口

· 英特尔酷睿i3/i5/i7/奔腾/赛扬处理器

· 英特尔H81/Q87芯片组

· DIMM DDR3/DDR3L 1600MHz内存,最大可达16GB(32GB)

· 2个英特尔千兆网口

· 10个串口 , 5个SATA3.0 (Q87)

· 4个USB3.0 ,7个USB2.0接口

· 1个Mini PCIe Slot(Q87), 1个mSATA

· 1个PCIe 16X, 2个PCIe 1X, 4个PCI 扩展槽

rocessor



CPU

4th Intel Core i3/i5/i7/Pentium/Celeron   Processor

Type

LGA1150

Chipset

Intel H81/Q87 PCH

BIOS

AMI UEFI

DRAM

Technology

DDR3/DDR3L 1600/1333MHz

Capacity

H81 SKU: Up to 16GB;     Q87 SKU: Up to 32GB

Socket

4(2) x 240-Pin DIMM Slot

Display

Graphics

Intel HD Graphics Support DX11.1 & OpenCL 1.2

Graphics Memory

Share System memory up to 1.7GB SDRAM

VGA

2 x VGA,    Resolution up to 2048x1536

DVI-D

1 (Ver: 1.2) Resolution up to 1920x1200

HDMI

1, Resolution up to 1920x1200

Multiple Display

2 Independent displays (H81);  3   Independent displays (Q87)

LAN

2 x Intel LAN (i211-AT)

Audio

Realtek ALC887 with Line-in/MIC/Line-out

Watchdog

Programmable from 1 to 255 Sec

Storage

SATA

H81:2xSATA3.0 +1x SATA2.0; Q87: 5 x SATA3.0

mSATA

1

RAID

RAID0/1/5/10 (Q87 SKU)

I/O

Serial

10 x RS232 (COM1 & COM2 Support RS232/422/485)

LPT

1

USB

H81: 4 x USB3.0 + 7 x USB2.0; Q87: 6 x USB3.0 + 7 x USB2.0

GPIO

4-In , 4-Out

PS/2

1

Expansion

Slot

PCIe x16

1 ( Ver: 3.0)

PCIe 1X

2 (Ver: 2.0)

PCI

4 (Ver: 2.3)

Mini PCIe

1 (Q87 SKU)

Power

Type

ATX

Form Factor

305mm x 244mm (ATX )

Environment

Operation Temp

& Humidity

-10~70/10~90%,

Non-condensing

Storage Temp

& Humidity

-20~80/10~90%

Non-condensing

Certification

EMC

CE / FCC

Model                      Description

SYM86368VGGA       Intel H81/Q87 ATX Board w/2VGA/HDMI/DVI/2GbE/10COM/mSATA/HDA
