ARX605便携CPCI工控机6U 5槽15寸显示屏
产品编号：201811121054
产品价格：¥
产品描述：ARX605便携CPCI工控机6U 5槽15寸显示屏
|
|
|
产品介绍
ARX605
6U, 5-slot CompactPCI Portable Instrument with 15" Touch screen display
Features
Aluminum Construction with shock absorbing rubber corners
Built-in 15” LCD display with touch screen, 1024x 768
Designed for portable instrument applications
6U CompactPCI and PICMG 2.5 H. 110 CT Bus
PICMG 2.1 Hot Swap compliant 32-bit or 64-bit 5-slot CompactPCI backplane with P3 & P5 rear IO
1U, 400W power supply, 100~240VAC
Built-in 1x slim DVD-ROM device
Industrial multi-language Keyboard with touchpad
The keyboard is integrated with the portable computer to protect the screen and easy to carry
Large handle provide convenience transportation of the portable computer with comfort and ease
Carrying case to manage portable PC with ease
Specifications| Model No |
ARX606 |
| Backplane |
5-slot 64-bit/ 66MHz 6U cPCI CT bus backplane
PICMG 2.5 H. 110CT bus
|
| cPCI standards |
PICMG 2.0 R3.0 CompactPCI Core Specification
PICMG 2.1 R2.0 CompactPCI Hot Swap Specification
PICMG 2.5 R1.0 CompactPCI computer Telephony Specification
|
| Form Factor |
6U CompactPCI
|
| Accessible Slots |
1 system slot & 4 Peripheral slots
|
| Rear I/O |
P3 & P5 rear I/O
|
| Display |
15" TFT LCD Monitor with touch screen, 1024x 768
|
| KB/MS |
Laptop type, multi-languages Keyboard/ touchpad
Keyboard layout: CH, FR, GR, KR, RU, SP, UK, US
|
| Power Supply |
1U, 400W, 100~240VAC, Auto switch |
| Drive bay |
Slim DVD-ROM |
| Construction |
Aluminum Construction with shock absorbing rubber corners |
| Dimension |
422Wx 285Hx 227D mm |
| Weight |
12 kgs |
| Carrying Case |
Padded carrying case with wheels |
|
Environmental Factors| |
Operating |
Non-Operating |
| Temperature |
0°C~45°C |
-20°C~80°C |
| Relative Humidity |
20%~90% |
10%~95% |
| Approval |
CE, FCC, RoHS |
Ordering Information| Product No. |
Description |
| ARX605 |
15" LCD with touch screen, 5-slot 6U CompactPCI Portable Computer, slim DVD-ROM, Carry case
|
|
|
